Wacker Neuson BS 60-4 Repair Manual

Repair Engine and Upper Machine Components
wc_tx001546gb.fm 73
Installation
Perform the procedure below to install the carburetor.
4.23.1 Install the carburetor (g), gaskets (h), and adapter (i).
4.23.2 Reconnect the linkage with screw
(f).
4.23.3 Reconnect the hose
(e).
4.23.4 Reconnect the fuel hose (d) and the compensation hose (h).
4.23.5 Reconnect the air hose
(c).
4.23.6 Reconnect the throttle cable (b).

Wacker Neuson BS 60-4 Specifications

General

Engine Manufacturer	Honda
Displacement	163 cm³
Operating Weight	66 kg
Percussion Rate	700 blows/min
Engine	Honda GX 160
Stroke	60 mm
Engine Type	4-stroke
Fuel Tank Capacity	3.0 liters
