14
Technical
data
BTS 630, 635
72
Operator's manual
14.2
Fuel mixture table
Note:
Only use f
uel in a
mixture rat
io of 1:50.
Gasoline volume in
liters (qt)
Oil volume
in liters
(qt)
1 (1.
06)
0.
02 (0.
02)
5 (5.
28)
0.1 (
0.1
1)
10 (10.5
7)
0.2 (0.2
1)
15 (15.8
5)
0.3 (0.3
2)
20 (21.1
3)
0.4 (0.4
2)
25 (26.4
2)
0.5 (0.5
3)
71
73
Table of Contents
Default Chapter
3
Table of Contents
3
1 Foreword
5
2 Introduction
6
Means of Representation for this Operator's Manual
6
Wacker Neuson Representative
7
Described Machine Types
7
Identification of the Machine
8
3 Safety
9
Principle
9
Qualification of the Operating Personnel
12
Protective Gear
13
Transport
14
Operating Safety
15
Safety During the Operation of Hand Machines
17
Safety During the Operation of Combustion Engines
17
Safety During Cut-Off Saw Operation
20
Maintenance
24
Safety and Information Labels
25
Safety and Information Icons
28
Safety Devices
29
4 Scope of Delivery
30
5 Structure and Function
31
Application
31
Functionality
31
6 Components and Operator's Controls
32
7 Transport
35
8 Initial Start up
36
Mounting the Cutting Attachment on the Outside
36
9 Use and Operation
41
Prior to Starting the Machine
41
Checks before Startup
41
Changing the Cutting Blade
41
Starting up
43
Starting the Engine
43
Operating the Machine
47
Decommissioning
48
10 Maintenance
49
Maintaining the Emission Control System
49
Maintenance Schedule
50
Maintenance Work
51
Cleaning the Machine
51
Topping up with Fuel
51
Tightening the V-Belt
53
Checking the Thrust Washers
54
Cleaning/Changing the Air Cleaner
55
Checking/Cleaning/Replacing the Spark Plug
57
Replacing the V-Belt
59
Replacing the Fuel Filter
62
Setting the Idle Speed
63
10Cleaning the Spark Arrestor
64
11Cleaning the Exhaust Port
65
11 Troubleshooting
67
12 Accessories
68
13 Storage
69
14 Technical Data
70
BTS 630, 635, 635S
70
Fuel Mixture Table
72
15 Emission Control Warranty
73
EC Declaration of Conformity
77
