10 Maintenance BTS 630, 635
62 Operator's manual
10.3.8 Replacing the fuel filter
Note: The fuel filter is located in the tank. The fuel filter cannot be cleaned.
Performing preparations
1. Switch off the engine.
2. Let the machine cool off.
3. Empty the tank.
Replacing the fuel filter
1. Unscrew the fuel cap.
2. Pull the fuel cap together with the retainer out of the fuel tank.
3. Pull the fuel filter out of the fuel tank with a wire hook.
4. Use a small screwdriver to loosen and remove the fuel filter.
5. Place a new fuel filter in position and press it in tightly.
6. Insert the fuel cap retainer into the fuel tank.
7. Position the fuel cap and tighten it.
Item Designation Item Designation
1 Fuel filter 3 Retainer
2 Fuel cap
