8 Initial start up BTS 630, 635
36 Operator's manual
8 Initial start up
8.1 Mounting the cutting attachment on the outside
By default the cutting attachment is mounted in the center of the machine.
The cutting attachment can be mounted on the outside to maneuver around
obstacles that are very close to the cutting line (e.g. curbs or brick walls).
When the cutting attachment is in the external position, using the guide cart
makes it even easier to see the cutting line.
Performing preparations
1. Switch off the engine.
2. Let machine cool off.
3. Detach the cutting blade.
Note: You must detach the cutting blade because otherwise, after the
conversion, the rotation direction of the cutting blade will no longer be the
same as that of the machine.
WARNING
Improper handling can result in injury or serious material damage.
f Read and follow all safety information of this operator's manual, see chapter
Safety.
