BTS 630, 635 8 Initial start up
Operator's manual 37
Converting the protective hood
1. Unscrew both hose connections and remove them.
2. Rotate the protective hood clockwise as far as it will go.
3. Unscrew and remove the vibration dampers.
4. Rotate the protective hood counter-clockwise until the mounting hole in the
vibration damper is visible.
5. Position the vibration damper and tighten it.
6. Unscrew the adjustment handle on top and remove it.
7. Position the adjustment handle below and tighten it.
Item Designation
1 Hose connection (2 pieces)
2 Vibration dampers
Item Designation
1 Adjustment handle
2 Vibration dampers
