3 Safety BTS 630, 635
28 Operator's manual
3.11 Safety and information icons
Item Symbol Description
1Choke.
2Start.
3 Stop.
4 The machine may only be operated with
a fuel mixture consisting of unleaded
gasoline and two-cycle engine oil.
The mixture ratio is 50:1.
5 Mark for setting the V-belt tension.
6 Machine's direction of rotation.
Mount the cutting blade such that its
rotation direction is the same as that of
the machine.
