If the filter or filter housing is damaged, stop
the engine immediately and replace the
damaged components. Failure to stop work
when the air filter of housing is damaged could
result in permanent damage
DINGO K94 - SERIES I, II, III Revision 1.3 September 2020
Page 17
Engine Oil
Refer to the engine manual for required frequen-
cies of oil changes, oil types, crankcase capacity
and viscosity.
Changing / Draining Oil
1. Start the engine and let if run for 5
minutes.This warms the oil so it drains better.
2. Park the Dingo so the drain side is slightly
lower to ensure that the oil drains completely.
3.Then lower the Dingo arms, chock the
wheels and turn the ignition key to OFF to stop
the engine. Remove the key.
4. Place the end of the hose in a pan.
5. Remove bung by turning counter
clockwise while holding the nut. Allow to drain.
6. When oil has drained completely, replace
the bung
Note:
Dispose of used oil in accordance
with local authority regulations.
7. Slowly pour approximately 80% of the spec-
ified amount of oil (refer to engine manual) into
the filler tube. Now check the oil level. Slowly
add additional oil to bring to FULL mark on
dipstick.
Changing Oil Filter
Refer to engine manual.
Spark Plugs
Removing, checking and cleaning spark plugs
(petrol only) - refer to engine manual.
Fuel Filter
Replace the fuel filter after every 100 hours or
yearly, whichever occurs first.
1. Never reinstall a dirty filter.
2. Lower the Dingo arms and turn the ignition
key to OFF to stop the engine. Remove the key.
3. Turn fuel tap off (by turning clockwise) to
block fuel flow. (Tap on diesel is lever on filter and
will be in horizontal position when off, tap on petrol
models is a knob on the petrol tank and should be
tightened to close / turn off).
4. Squeeze the ends of the hose clamps
together and slide them away from the filter.
5. Place a drain pan under the fuel line to
catch any spillage, then remove the filter from
the fuel lines.
6.Install a new filter and move the hose
clamps close to the filter.
7. Remove clamp blocking fuel flow.
Draining the Fuel Tank
DANGER! Petroleum can be extremely
flammable and highly explosive. To avoid a fire
of explosion that may burn yourself, others, or
cause property damage:-
•Drain petrol from the fuel tank when the
engine is cold. Do this outdoors in an open area.
• Wipe up any petroleum that spills.
• Never drain petroleum near an open flame
or where a spark may ignite petroleum fumes
• Never smoke while handling fuel
1. Park the Dingo on a level surface, to
ensure fuel tank drains completely.
2. Lower the Dingo arms and turn the ignition
key to OFF to stop the engine. Remove the key.
