8. Note: Proceed to next step if auxiliary
hydraulics are required with attachment.
DINGO K94 - SERIES I, II, III Revision 1.3 September 2020
Page 14
9. IMPORTANT: Make sure all foreign
matter is cleaned from hydraulic
connections before making connections.
10. With the engine turned off move the auxiliary
hydraulics lever to the forward, backward, and
back to neutral position to relieve hydraulic
pressure at the hydraulic couplers.
11.Remove protective plugs from the hydraulic
couplers on the Dingo (The hydraulic couplers
are located on the inside of the left arm). Connect
plugs together to prevent contamination during
operation.
12.Slide collar back on hydraulic coupler and
connect attachment couplers to machine
couplers. There will be two connections to make.
13.Confirm that connection is secure by
pulling on the hoses.
14.Connecting the 4in1 Bucket is done in the
same way except the receiving couplers for the
4in1 bucket are located on the inside of the right
arm of the Dingo. No mistake can be made as the
4in1 couplers are smaller and will not fit the
auxiliary couplers
Disconnecting
1.Lower attachment to the ground or onto a
trailer.
2. Turn the ignition key OFF to stop the engine.
3.Move the auxiliary hydraulics lever forward,
backward and back to neutral position to relieve
hydraulic pressure at the hydraulic couplers.
4.Slide collar back on the hydraulic coupler and
disconnect attachment couplers from machine
couplers. (Note: if this is difficult return to step 3
and repeat).
5.IMPORTANT: Connect attachment hoses
together to prevent contamination during storage.
6. Install protective caps onto Dingoes
hydraulic couplers.
7. Disengage the attachment lock pins by
turning them to the outside.
8. Start engine, tilt the mount plate forward
and back machine away from the attachment.
