Wacker Neuson DINGO K9-4 - Hydraulic Pipes on K94

Hydraulic Pipes On K94
DINGO K94 - SERIES I, II, III
Revision 1.3 September 2020
Page 36
QTY PART NO. CODE DESCRIPTION NOTES KOHL. TNE TNV PERK.
1
9001194411
EX Flow control to remote bank
   
1
9001194412
FP hi/low valve to flow control
   
1
9001194413
CD Main bank to dump pipe
   
1
9001194414
AP Hi/Low To Aux Bank
   
1
9001194415
C1 R Rear wheel motor
   
1
9001194416
C2 R Front Wheel Motor
   
1
9001194417
C3 L Rear Wheel Motor No Relief
   
1
9001194418
C4 L Front Wheel Motor No Relief
   
2
9001194419
C5 Front to rear wheel motor pipe
   
1 OBSOLETE . L Rear Wheel Motor With Relief Was 9001194436
   
1 OBSOLETE C4-1 L Front Wheel Motor With Relief
Was
9001194437
   
1 OBSOLETE DD Diesel Dump Pipe Was 9001194420
   
1
9001194421
DV1 Diesel Wheel motor 1 c-bank to o/c valve
   
1
9001194422
DV2 Diesel Wheel motor 2 c-bank to o/c valve
   
1
9001194423
DV3 Diesel Wheel motor 3 c-bank to o/c valve
   
1
9001194424
DV4 Diesel Wheel motor 4 c-bank to o/c valve
   
1
9001194425
AI Remote to Large Aux 1
   
1
9001194426
A2 Remote to Large Aux 2
   
1
9001194427
A3 Remote to Small Aux 1
   
1
9001194428
A4 Remote to Small Aux 2
   
1
9001194429
T1 Control Bank to Crowd Hose 1
   
1
9001194430
T2 Control Bank to Crowd Hose 2
   
1
9001194431
DD Diesel Dump Pipe External Filter (Current)
   
1 9001194436 C3 L Rear Wheel Motor with Relief
   
1
9001194437
C4 L Front Wheel Motor with Relief
   
1
9001194438
DDA Diesel Dump Pipe Internal Filter (Current)
   
1
9001194476
F1 Filter to Tank Dump
   
1
9001194492
DV1-2 Diesel Wheel motor 1 c-bank to o/c valve
   
40mm Rear
1
9001194493
DV2-2 Diesel Wheel motor 2 c-bank to o/c valve
   
40mm Rear
1
9001194494
DV3-2
Diesel Wheel motor 3 c-bank to o/c valve
   
40mm Rear
1
9001194495
DV4-2 Diesel Wheel motor 4 c-bank to o/c valve
   
40mm Rear
1 K9001194477 PV1 Petrol Wheel motor 1 c-bank to o/c valve
   
1 9001194478 PV2 Petrol Wheel motor 2 c-bank to o/c valve
   
1 9001194479 PV3 Petrol Wheel motor 3 c-bank to o/c valve
   
1 9001194480 PV4 Petrol Wheel motor 4 c-bank to o/c valve
   
1 9001194432 PD Petrol Dump Pipe External Filter (Current)
   
1 9001194439 PDA
Petrol Dump Pipe Internal Filter (Not Yet
   
Existing)
