Wacker Neuson DINGO K9-4 - Page 35

Remote Control Bank Part Numbers & Descriptions
DINGO K94 - SERIES I, II, III
Revision 1.3 September 2020
Page 35
Item Qty Part No. Description Notes
1 1
9330003051
REMOTE BANK
2 2
9316375503
NIPPLE M/M 3/8" BSPP x 9/16" JIC
9316375502 has been superceded
REPLACEMENT SEAL = 9330006042
3 2
9316377502
NIPPLE M/M 3/8" BSPP x 7/8" JIC ENC/SEAL
9316377501 has been superceded
REPLACEMENT SEAL = 9330006042
4 1
9312470000
BLANKING PLUG 1/2” BSPP
5 4
9312370000
BLANKING PLUG 3/8” BSPP
6
1
9315376501
ELBOW M/M 3/8" BSPP x 3/4" JIC 90°
9315376500 has been superceded
REPLACEMENT O-RING = 9330006016
7 2
9315477501
ELBOW M/M 1/2” BSPP x 7/8” JIC REPLACEMENT O-RING = 9330006015
8 1
9315377501
ELBOW M/M 3/8" BSPP x 7/8" JIC 90° 9315377501 has been superceded
REPLACEMENT O-RING = 9330006016
9 1
9001194482
REMOTE HANDLE BENT
10 1
9001194483
REMOTE HANDLE Z BEND
11 1
9001194481
REMOTE HANDLE STRAIGHT. SHORT
12 1
9318111100
MALE Q/R FLUSH FACE
13 1
9318112100
FEMALE Q/R FLUSH FACE
14 2
9316372701
NIPPLE M/M 3/8" BSPP x 1/4" BSPP 9316372700 has been superceded
15 3
9111311060
BOLT HEX M8 x 60mm
16 3
9122131000
NUT NYLOC M8
17 1
9001194414
PIPE – PUMP SELECTOR TO REMOTE BANK (AP)
18 1
9001194413
PIPE – MAIN BANK TO DUMP (CD)
19 1 9317769575 TEE F/M/M 7/8" JIC x 1 1/16" JIC x 7/8"
20 1
9001194428
PIPE - REMOTE BANK TO 3/8” AUX (A4)
21 1
9001194427
PIPE - REMOTE BANK TO 3/8” AUX (A3)
22 1
9001194426
PIPE - REMOTE BANK TO 1/2” AUX (A2)
23 1
9001194425
PIPE - REMOTE BANK TO 1/2” AUX (A1)
24 2
9316555500
NIPPLE M/M 9/16" JIC x 9/16" JIC BULKHEAD
25 2
9330000018
15 mm HOSE CLAMP BLOCK
26 1
9330000016
15mm HOSE GUIDE PLATE
27 1
9001194411
PIPE - FLOW CONTROL TO REMOTE BANK (EX)
28
1
9001194450
1/2” HYD-HOSE 1/2” FEMALE QUICK RELEASE
TO FRONT FITTING (1150mm)
29 1
9001194451
1/2” HYD-HOSE 1/2” MALE QUICK RELEASE TO
REAR FITTING (1180mm)
30 1
9001194452
1/4” HYD-HOSE 3/8” FEMALE QUICK RELEASE
TO FRONT FITTING (1105mm)
31 1
9001194453
1/4” HYD-HOSE 3/8” MALE QUICK RELEASE TO
REAR FITTING (1130mm)
