Electricwirning-Diagramm
SK00673GB.fm 45
9. Electricwirning-Diagramm
1 Bush plug
2 Button switch
3 Wire harnes
4 Control lamp (Battery)
5 Central plug
6 Socket head cap screw DIN912 - M8x16
7 Piezoelectric buzzer
8 Mass line
9Battery
10 Positive pol strop
11 Starter
12 Nose cap
13 Fixing, fuse
14 Cable yarn
