BA ET16 de* 1.0 * et16b510.fm 5-17
Operation 5
1. Raise the control lever base.
2. Make sure that the lever A located to the left under the operator’s seat
is in position 1.
3. Lower the control lever base.
4. Set the dozer blade to the desired position:
Information
In order to ensure maximum stability during work:
Only perform work with an extended telescopic travel gear.
Lower the stabilizer blade and turn out the extensions.
Position Function
1 The dozer blade is actuated.
2 The telescopic travel gear is actuated.
Fig. 124
1
2
A
Fig. 125
B
Fig. 126
Function Position
Raise stabilizer blade Pull lever B backward
Lower stabilizer blade Push lever B forwards
