BA ET16 de* 1.0 * et16t900.fm 9-1
Technical data 9
9 Technical data
9.1 Models and trade names
– see chapter “ Overview of models and trade name” on page 3-2
9.2 Engine
Engine ET16
Product Yanmar
Type 3TNV76-SNS2
Design Water-cooled 3-cylinder diesel engine
Intake system Naturally aspirated engine
fuel injection system Indirect
Engine management Mechanical
Displacement 1116 cm³ (68 cu. in.)
Nominal bore and
stroke
76 x 82 mm (2.9 x 3.2 in)
Power
13.2 kW at 2,200 rpm
(17.7 hp at 2,200 rpm)
Max. torque
65.8 Nm at 1600 rpm
(48.5 ft./lbs. at 2,200 rpm)
Max. engine speed
without load
2,375 +/-25 rpm
(2,375 +/-25 rpm)
Idling speed
1,300 +/-50 rpm
(1,300 +/-50 rpm)
Starting aid Glow plug (preheating time 4 seconds)
Exhaust values
according to
EPA – Tier IV final (up to 2012)
