9-2 BA ET16 de* 1.0 * et16t900.fm
9 Technical data
The machine has about 17 % less output at altitudes over 800 m (2625 ft)
above see level. However, this does not affect excavator operation
(Yanmar 3TNV80F-SSNS2).
Engine ET16
Product Yanmar
Type 3TNV80F-SSNS2
Design Water-cooled 3-cylinder diesel engine
Intake system Naturally aspirated engine
fuel injection system Indirect
Engine management Mechanical
Displacement 1,266 cm³ (77 in³)
Nominal bore and
stroke
80 x 84 mm (3.1 x 3.3 in)
Power
13.2 kW at 2200 rpm
(17.7 hp at 2,200 rpm)
Max. torque
65.8 Nm at 1600 rpm
(48.5 ft/lbs at 2,200 rpm)
Max. engine speed
without load
2375 +/- 25 rpm
(2,375 +/- 25 rpm)
Idling speed
1300 +/- 50 rpm
(1,300 +/- 50 rpm)
Starting aid Glow plug (preheating time 4 seconds)
Exhaust values
according to
EPA – Tier IV final (from 2012)
