6-8 BA ET16 de* 1.0 * et16t600.fm
6 Transportation
6.3 Transporting the machine
+ 1. The driver of the transport vehicle must observe the following before
departure:
- Permitted overall height, width and weight of the transport vehicle
including the excavator.
- The legal regulations of the countries where transport is to take
place.
2. Close the exhaust pipe before transporting the machine through wet
weather.
Revolving superstructure lock
The revolving superstructure lock locks the revolving superstructure
during transport.
Possible serious machine damage.
► Do not rotate the locked revolving superstructure.
Locking the upper carriage
• Align the upper carriage and the travel gear correctly.
• Raise bolt A and bring into position 2.
Unlocking the upper carriage
• Align the upper carriage with the travel gear.
• Raise bolt A and bring into position 1.
