BA ET16 de* 1.0 * et16t900.fm 9-23
Technical data 9
ET16
Height (standard travel gear) 2283 mm (89 in)
Height (telescopic travel gear) 2317 mm (91 in)
Upper carriage width 980 mm (39 in)
Width 990 mm (39 in)
Width with retracted telescopic travel gear 990 mm (39 in)
Width with extended telescopic travel gear 1300 mm (51 in)
Width with folded-in dozer blade 990 mm (39 in)
Width with folded-out dozer blade 1300 mm (51 in)
Transport length (short stick) 3645 mm (12‘)
Transport length (long stick) 3605 mm (11′ -10″)
Max. digging depth 2240 mm (88 in)
Length with short shovel arm 940 mm (37 in)
Length with long shovel arm 1100 mm (43 in)
Max. vertical digging depth 1640 mm (65 in)
Max. digging height 3390 mm (11′ -2″)
Max. tilt-out height 2370 mm (93 in)
Max. digging radius 3700 mm (12′ -2″)
Max. reach at ground level 3650 mm (12')
Min. tail end slewing radius 1075 mm (42 in)
Max. tail end lateral projection (90° rotation of upper carriage) 580 mm (23 in)
Max. boom displacement to bucket center (right side) 432 mm (17 in)
Max. boom displacement to bucket center (left side) 287 mm (11 in)
