BA ET16 de* 1.0 * et16i400.fm 4-25
Putting into operation 4
Designation See page
1 Boom swivel pedal
5-24
2 Drive levers/accelerator pedals
5-1
3 Auxiliary hydraulics pedal
5-22
4 Foot-operated tip switch for hydraulic quickhitch (option)
5-30
5 Control lever on the left
5-10
6 Control lever on the right
5-13
7 Temperature controller (for cabin option)
5-12
8 Revolving superstructure lock
6-8
9 Control lever base
4-35
10 Stabilizer-blade lever
5-16
11 Display element
4-26
12 Starter
4-34
13 Operator's seat/safety belt
4-7, 4-9
14 Throttle
5-1
15 Changeover for stabilizer blade/travel gear extension/retraction
5-16, 5-19
16 Switch panel
4-26
