BA ET16 de* 1.0 * et16i400.fm 4-39
Putting into operation 4
1. Move vehicle Y close to machine X so that the length of the battery
jumper cables is sufficient.
2. Stop the engine of vehicle Y.
3. Open the left side cover of the vehicle X
– see chapter “ Cover on the left” on page 7-16.
4. Open the vehicle engine hood Y.
5. Connect the battery jumper cables in the following order: A – B – C –
D.
6. Start the engine of vehicle Y.
7. Wait five minutes for the empty battery to be charged a little.
8. Start the engine of machine X.
9. Switch on the boom light of machine X in order to avoid voltage peaks
and to protect the electronic system.
10.Disconnect the battery jumper cables in the following sequence: D – C
– B – A.
Designations/symbols Meaning
X Machine with empty battery
Y Vehicle with full battery
A Positive/machine X
B Positive/vehicle Y
C Negative/vehicle Y
D Negative/machine X
Full battery
Dead battery
