5-30 BA E19 en* 1.0 * E19_10_510.fm
5 Operation
AUX III
Crushing hazard due to rotating movements of the Powertilt unit!
Rotating the Powertilt unit can cause serious injury or death.
► Do not allow anyone to stay in the danger zone.
The Powertilt unit may only be installed and removed by a Wacker
Neuson service center!
For more information, see Easy Lock/Powertilt with Easy Lock
Operator’s Manual.
Toggle between AUX III and AUX II with touch button A on the left
joystick.
If the AUX III function is selected, the symbol appears in the center of the
display for a few seconds.
Fig. 163 (symbolic representation)
Rotation to
the left
Rotation to
the right
Function
1
1. Depending on the system used or the valid norm, the rotation of direction may differ.
Operation
Rotation to the left Press switch B to the left
Rotation to the right Press switch B to the right
