Operation LTN
4.15 Manually Rotating the Mast
Overview
The operator can rotate the mast 360° while the tower is lowered.
Procedure
To rotate the mast, perform the procedure below.
1. Pull out the locking pin (a) on the bottom of the mast.
2. Rotate the mast to the desired position.
3. Engage the locking pin (a).
Note: Be sure the locking pin seats into a groove on the sprocket.
