Machine Setup LTV
Continued from the previous page.
Aiming Left or Right
1. Grasp the light fixture and aim it to the left or right. If necessary, loosen the
bracket nut (c) to allow movement of the fixture.
NOTICE: Do not loosen the nut (b). Damage to the light fixture may occur.
2. If loosened, tighten the bracket nut (c) when the light is aimed properly.
Note: The bracket nut (c) should be only tight enough so that slight resistance is
present when aiming the fixture.
3. Repeat steps 1–2 for each remaining light fixture, if desired.
To Next Page
