Machine Setup LTV
4.9 Lowering the Tower—Manual Winch System
Requirements
■ Lights are turned off
■ Engine is stopped
■ Outriggers are extended and locked in place
Procedure
Perform the procedure below to lower the tower.
1. Turn the handle on the telescoping winch (a) counterclockwise (“cable out”
direction) until the tower is lowered completely.
This procedure continues on the next page.
WARNING
Tipping/falling hazards. Certain actions may cause the tower to fall or the machine
to tip over.
► Do not raise the tower or operate the Light Tower in high winds.
► Do not touch the winch pawl while the tower is raised!
WARNING
Personal injury hazard. Bystanders can be struck by the tower as it is being raised
or lowered.
► Do not allow anyone to stand near the front of the machine while raising or
lowering the tower.
wc_gr013771
a
b
