LTV Machine Setup
4.7 Manually Rotating the Light Bar
Overview
The operator can rotate the light bar 360° while the tower is lowered.
Procedure
Perform the procedure below to rotate the light bar.
1. Loosen out the locking knob (a).
2. Rotate the light bar to the desired position.
3. Tighten the locking pin (a).
Note: Before towing, aim the light bar forward. Be sure the locking pin seats into a
hole in the light bar. Holes are positioned at 90° angles.
