LTV Machine Setup
Continued from the previous page.
Procedure Perform the procedure below to raise the tower.
NOTICES ■ Do not attempt to raise the tower if the winch is damaged or not operating
properly, or if the winch cables are worn or damaged.
■ The tower and light bar can be rotated 360°. If you wish to position the light bar
so the lights illuminate to the left, to the right, or to the rear, the light bar should
be rotated when the tower is fully lowered. See topic Manually Rotating the Light
Bar.
Raising the
tower
1. Check the operation of the telescoping winch (a). Turn the telescope rotary
switch (b) on the control panel to the up position.
2. Continue to hold the telescope rotary switch until the tower is at the desired
height. Release the switch when the tower is at the desired height.
wc_gr013772
a
b
