Maintenance P35A
5.4 Air Cleaner
The engine is equipped with a single element air cleaner. Service air cleaner
frequently to prevent carburetor malfunction.
NOTICE: Do not run engine without air cleaner. Severe engine damage will occur.
To serv i ce :
1. Press the latch (a) on the side of the air cleaner cover (b), and remove the
cover.
2. Check the filter (c) to be sure it is in good condition. Replace damaged filters.
3. Wash filter element (c) in solution of mild detergent and warm water. Rinse
thoroughly in clean water. Allow element to dry thoroughly. Soak element in
clean engine oil and squeeze out excess oil.
4. Re-install the filter (c) and air cleaner cover (b).
WARNING
Fire and explosion hazard.
► Do not use gasoline or other types of low flash point solvents for cleaning the
air cleaner. A fire or explosion could result.
