RS 800 /... Technical Data
wpm_td000358gb.fm 13
3. Technical Data
3.1 Engine
Engine Power Rating
Net power rating per SAE J1349. Actual power output may vary due to
conditions of specific use.
Part No. RS 800A
0630011
RSS 800A
0630012
Engine
Engine Type
4-stroke, overhead valve,
single cylinder
Engine Make
Honda
Engine Model
GX 340 K1 QA2 GX 340 K1 QAE2
Max. rated power @ rated speed
kW (Hp) 7.1 (9.5) @ 3600 rpm
Spark Plug
(NGK) BR 6ES
Electrode Gap
mm (in) 0.7–0.8 (0.028–0.031)
Operating Speed
rpm 2400
Valve Clearance (cold)
intake:
exhaust:
mm (in.) 0.15 (0.006)
0.20 (0.008)
Air Cleaner
type Dual Element
Engine Lubrication
oil
grade
SAE 10W30
Service Class SF, SG
Engine Oil Capacity
l (oz.) 1.1 (37)
Fuel
type Regular unleaded gasoline
Fuel Tank Capacity
l (qts.) 6.8 (7.2)
