Wacker Neuson RS 800A User Manual

Operation RS 800 /...
wpm_tx001253gb.fm 16
4. Operation
4.1 Operation and Service Locations
See Graphic: wc_gr003471
RSS 800A
RS 800A
Ref. Description Ref. Description
1 Handle locking pin 7 Exciter control
2 Sprinkler tube 8 Water fill cap
3 Water control valve 9 Fuel tank
4 Scraper bar 10 Lifting eye
5 Tie-down 11 Hydrostatic drive release
6 Forward/reverse control lever 12 Control box
Ref. Description Ref. Description
1 Handle locking pin 7 Exciter control
2 Sprinkler tube 8 Water fill cap
3 Water control valve 9 Fuel tank
4 Scraper bar 10 Lifting eye
5 Tie-down 11 Hydrostatic drive release
6 Forward/reverse control lever
