Torque Values
Torque Values (continued)
Inch Fasteners (SAE)
Size Nm ft.lb. Nm ft.lb. Nm ft.lb. Metric Inch Metric Inch
No.4 0.7 *6 1.0 *14 1.4 *12 5.5 1/4 – 3/32
No.6 1.4 *12 1.9 *17 2.4 *21 8 5/16 – 7/64
No.8 2.5 *22 3.5 *31 4.7 *42 9 11/32 – 9/64
No.10 3.6 *32 5.1 *45 6.8 *60 – 3/8 – 5/32
1/4 8.1 6 12 9 16 12 – 7/16 – 3/32
5/16 18 13 26 19 33 24 13 1/2 – 1/4
3/8 31 23 45 33 58 43 – 9/16 – 5/16
7/16 50 37 71 52 94 69 16 5/8 – 3/8
1/2 77 57 109 80 142 105 19 3/4 – 3/8
9/16 111 82 156 115 214 158 – 13/16 – –
5/8 152 112 216 159 265 195 24 15/16 – 1/2
3/4 271 200 383 282 479 353 – 1-1/8 – 5/8
1 ft.lb. = 1.357 Nm * = in.lb. 1 inch = 25.4 mm
