WM 90 Repair Disassembly Procedures
wc_tx000389gb.fm 41
7. Disassembly Procedures
7.1 Removing Engine from Rammer
See Graphic: wc_gr001954, wc_gr003661, wc_gr001956, and wc_gr001957
7.1.1 Disconnect the spark plug cap (a) from the spark plug.
7.1.2 Disconnect the fuel line (b) from the carburetor and plug the line.
7.1.3 Disconnect the stop switch wire (c).
7.1.4 Disconnect the wiring (k) from the low-oil unit (l) (if equipped).
7.1.5 Remove the M8 x 16 bolt and washer (d) securing the guard to the
engine.
7.1.6 Remove the M8 bolt and washer (e) securing the guard to the rammer
crankcase.
7.1.7 Remove the six M8 bolts (f) securing the lower guard to the engine and
remove the guard.
7.1.8 Remove the wire running from the engine to the low-oil unit (if
equipped).
7.1.9 Loosen the retainer (g) from the throttle cable. Pry open the clamp (h)
and remove the throttle cable.
7.1.10 Loosen the clamp (i) securing the air intake hose to the carburetor and
remove the hose.
7.1.11 Remove the four nuts (j) securing the engine to the adapter and
remove the heat shield and the engine.
