3. On each side of the handle install bolt and
tighten wing nut over lock washer
2. Insert handle
Start
1
Start
1
Assemble Your
Wagner Paint
Crew
What you’ll need
• Phillips screwdriver
• Wrench (2)
Note: Do not plug in the
power cord until assembly is
complete.
4. Thread one end of spray
hose to outlet valve on sprayer
5. Tighten with wrench 6. Thread other end of spray
hose to spray gun
7. Hold spray gun with one wrench and tighten
hose nut with other wrench
THREAD
THREAD
TIGHTEN
65
2 3
4 5 6 7
Before You Start • Assemble Your Wagner Paint Crew
