16
AC 4600 Pro
C
D
E
F
G
K
A
H
J
L
I
M
B
B_02673
P
ro
fes
sio
n
a
l
OPERATING MANUAL
EDITION 02/2009
PART NO. DOC394871
5 STARTING UP AND OPERATING
5.1.1 TYPICAL AIRCOAT SPRAYING SYSTEM
A Paint-pump
B Pressure air shut off valve
C Pressure regulator
D Air pressure regulator with fi lter
E Earthing cable
F Air hose, el. conductive
The pray gun 4600AC Professional must be used a part of a spraying system. The spraying
system shown in the fi gure is only one example of an electrostatic Aircoat spraying system.
It is not an actual system design. Contact your Wagner distributor for assistance in design-
ing a system to meet your needs.
The operating instructions and the safety regulations for the additional system compo-
nents used must be read before starting-up.
5.1 INSTALLATION AND CONNECTION
WARNING
Incorrect installation/operation!
Risk of injury and damage to equipment
When putting into operation and for all work, read and follow
the operating instructions and safety regulations for the addi-
tionally required system components.
SIHI_0050_GB
G AirCoat Gun
H High-pressure fl uid hose
I High pressure fi lters/ Relief valve
J Return
K Stand trolley
L Suction system
M Compressed air main
