9.1.1 NOZZLE INSERTS RXX
Part No. Description Marking Volume fl ow* Jet-ø **
132720 Nozzle insert R11 11 0.16; 160 approx. 250; 9.84
132721 Nozzle insert R12 12 0.22; 220 approx. 250; 9.84
132722 Nozzle insert R13 13 0.27; 270 approx. 250; 9.84
132723 Nozzle insert R14 14 0.34; 340 approx. 250; 9.84
132724 Nozzle insert R15 15 0.38; 380 approx. 250; 9.84
132725 Nozzle insert R16 16 0.43; 430 approx. 250; 9.84
132726 Nozzle insert R17 17 0.48; 480 approx. 250; 9.84
132727 Nozzle insert R18 18 0.53; 530 approx. 250; 9.84
132728 Nozzle insert R19 19 0.59; 590 approx. 250; 9.84
132729 Nozzle insert R20 20 0.65; 650 approx. 250; 9.84
132730 Nozzle insert R21 21 0.71; 710 approx. 250; 9.84
132731 Nozzle insert R22 22 0.77; 770 approx. 250; 9.84
* Volume fl ow in ml/min; cc/min water at 10 MPa; 100 bar; 1450 psi.
** Jet width in mm; inches at a distance of 30 cm; 11.8 inches from the object and at a
pressure of 10 MPa; 100 bar; 1450 psi, synthetic resin paint, 20 DIN4 seconds.
9.1 ROUND JET NOZZLE CAP
Part No. Description
394180 Round jet nozzle cap
(without nozzle insert)
9 ACCESSORIES
9.1.2 NOZZLE SCREWED CONNECTION COMPL.
Part No. Description
132922 Nozzle screwed connection compl.
