10.2 SPARE PARTS LIST AC4600 PROFESSIONAL
Spare parts list AC 4600 Professional
Pos K Qty
Part No.
Description
1
1 394150 AC 4600 Professional; NPSM1/4“ (blue) compl.
1
1 394151 AC 4600 Professional; NPSM1/4“ (red) compl.
1
1 394152 AC 4600 Professional; NPSM1/4“ (green) compl.
2
1 9999501 Screw spring Paint
3
1 9999500 Screw spring Air
4
1 394256 Tension sleeve compl.
5
1 394333 Spring cover 25 MPa; 250 bar; 3625 psi
6
1 394924 Air tappet complete
8
◆
1 2311320 Valve rod unit assy.
10
1 394327 Sealing screw
11
✭
◆
1 394328 Gasket
12
✭
◆
1 9971445 O-ring
13
◆
1 379411 Nozzle ACF3000 11/40
(other nozzle sizes see chapter 9.2)
14
✭
◆
1 394339 Sealing ring
15
✭
◆
1 9974245 O-ring
16
✭
◆
1 394922 Valve seat compl.
17
✭
◆
1 394338 Seal Nozzle
18
1 394330 Chuck
19
1 394257 Valve tappet compl.
20
1 394318 Nut
21
1 394601 Trigger
22
1 394319 Screw
23
1 394334 Safety catch
24
1 9935088 Cylindrical shaft
3 4
✭
◆
1 394920 Valve rod compl.
3 5
✭
◆
1 394323 Rod seals
36
◆
1 394910 Air cap LV compl. (red)
36
◆
1 394911 Air cap HV compl. (blue)
36
◆
1 394912 Air cap (green)
50 1 394309 Valve tappet
51
✭
◆
1 179338 Air valve seal
◆ = Wearing part
✭ = Included in service set
● = Not part of standard equipment for spray gun. Available, however, as additional
extra
