29
AC 4600 Pro
B_02704
OPERATING MANUAL
EDITION 02/2009
PART NO. DOC394871
1. Finishing work and cleaning.
2. Relieve spray gun and unit pressure.
3. Secure gun with trigger safety catch.
4. Losen complete swivel by hand through turning at the handle
tube (C) and drive out downward together with the material
hose.
5. Pull fi lter insert (A) out of the fi lter housing (B).
6. Flush swivel, fi lter housing and fi lter insert (A) with cleaning
agent.
7. Push in cleaned or new fi lter insert (A) with cone (X) upward into
the fi lter housing.
8. Put handle tube with female hexagon on swivel and screw from
down over the fi lter insert onto the fi lter housing by hand.
Note:
Do not unscrew the fi lter housing. The
nut must only be unscrewed by WAGNER
- Service-Agency.
