AC 4600 Pro
OPERATING MANUAL
EDITION 02/2009
PART NO. DOC394871
Spare parts list AC 4600 Professional
Pos K Qty
Part No.
Description
52
✭
◆
1 179395 Seal
53
✭
◆
1 394322 Cap
55
●
1 394336 Nozzle body
56
◆●
1 128327 Sealing nipple
57
◆●
1 132516 Nozzle screw connection compl.
58
●
1 132351 Nozzle screw connection holder
59
●
1 394308 Union nut
60
●
1 394337 Nozzle nut
61
◆●
1 132... Nozzle insert R (various dimensions see chap. 9.1.1)
62
●
1 394180 Round jet nozzle cap (see chap. 9.1)
63
◆●
1 132922 Nozzle screw connection compl.
64
◆
1 43235 Filter insert yellow, 100 mesh
(other fi lter types see chapter 9.2)
65
✭
◆
1 364340 Seal fi lter
66
✭
◆
1 43590 Compression spring
67
◆
1 347706 Swivel compl. paint
68 1 364349 Handle tube
69
◆
1 364938 Swivel Air
70 1 394615 Filter tube AC 4600 Pro NPS 1/4“
1 394942 Service set AC 4600 Professional
◆ = Wearing part
✭ = Included in service set
● = Not part of standard equipment for spray gun. Available, however, as additional
extra
