Parameter Value Description
C16
External recipe selection
(Pulse controller using remote
control bush)
OFF
(factory setting)
The recipe is selected using 4 dierent
pulse lengths to select recipes 1-4.
This setting is compatible with the CCM
Prima.
ON The recipe is selected by using an extended
pulse/pause protocol to select all 50 recipes
and call up the ush function.
This setting should be used if control by a
programmable logic controller (PLC) is the
same as with a ProTech Sprint system.
For protocol, see service manuals for EPG-
SPRINT XE.
C17
Powder output
Increase in powder output
by activating the feed and
atomizing air in parallel. Both
these airs must be combined
externally by a Y-piece and
supplied to the injector's feed
air connection. The additional
volume diers depending on
injector type. The atomizing
and Tribo air is no longer
available to the spray gun
and must be obtained from a
dierent source.
OFF
(factory setting)
"Standard" setting for separate hosing for
feed, dosing and atomizing air.
ON The feed air and atomizing air outputs are
combined for a larger feed air quantity
(higher powder output quantity).
Attention: The Tribo and atomizing air is no
longer available.
C18
Display luminance
The display luminance can be
set to one of three levels.
0 Full display luminance (default setting)
1 Medium luminance (reduced brightness)
2 Minimum luminance (brightness greatly
reduced)
C19 Delete created recipes
NO
(factory setting)
No action.
res All recipes are reset to the delivery
condition if "res" is saved with button 25.
C20
Reset unit to delivery
condition
NO
(factory setting)
No action.
res All settings except recipes are reset to the
delivery condition if "res" is saved with
button 25.
