Operating manual Piston Pump EvoMotion 5-125
14 Spare Parts
56 Order number 2316596 | Edition 03/2021
Pos K Stk Order no. Designation
4 1 2369375 Cylinder motor
5 1 3055157 Hexagon nut with clamp
6 1 9992757 Threaded elbow fitting
7 ♦⋆ 2 G903.06 Damper
8 ♦⋆ 1 L413.06 Seal DE 80
9 1 A164.01 Motor piston
10 ♦⋆ 1 L802.08 Sliding ring
11 ♦⋆ 1 L110.06 O-ring
12 1 D404.12 Piston rod, M80 EM
13 ♦⋆ 2 L109.06 O-ring
14 1 A408.12 Air tube, M80 EM
15 1 T616.00C Motor flange, complete M80 EM, at bottom
16 ♦ 1 P498.00KNE Reversing valve ISO N/1
17 1 367258 Grounding, complete
18 ♦⋆ 1 L403.06 Rod seal
19 ♦⋆ 1 T703.00 Sensor below, M80
20 1 K606.02 Lock washer for waves
21 1 A160.01A Washer
22 ♦⋆ 1 369290 Pilot valve
23 ♦ 2 H505.07 Silencer
24 1 9920106 Washer
25 1 M432.00 Reducing fitting
26 2 9992265 Angled threaded fitting
27 1 9992831 Loctite 542
28 4 9907241 Hexagon socket head cap screw
29 1 9998808 Mobilux EP 2 grease
30 1 9998157 Loctite 480
31 ♦ 1 G735.06AB Valve sealing
32 1 A818.71B Valve plate
33 4 9920104 Washer
34 4 9900386 Hexagon socket head cap screw
35 ♦ 1 P498.00 Reversing valve, P/1 SP/NUM (see chapter Reversing Valve [859])
1 T910.00 Service set, air motor EM 30-30/ 40-15/ 5-125
♦ = wearing parts
⋆ = Included in service set
