Operating manual Piston Pump EvoMotion 5-125
6 Assembly and Commissioning
26 Order number 2316596 | Edition 03/2021
6 ASSEMBLY AND COMMISSIONING
6.1 TRAINING OF ASSEMBLY/COMMISSIONING PERSONNEL
– The assembly and commissioning personnel must have the technical skills to safely
commission the device.
– When assembling, commissioning and carrying out all work, read and follow the
operating manuals and safety regulations for the additionally required system
components.
A skilled person must check to ensure that the device is in a reliable state after it is
assembled and commissioned.
6.2 STORAGE CONDITIONS
Until the point of assembly, the device must be stored in a dry location, free from vibrations
and with a minimum of dust. The device must be stored in closed rooms.
Die Lufttemperatur am Lagerort muss in einem Temperaturbereich zwischen -20°C und
+60°C; -4°F und +140°F liegen.
The relative air humidity at the storage location must be between 10 and 95% (without
condensation).
6.3 INSTALLATION CONDITIONS
The air temperature at the installation site must be in a range between 4°C and 40°C; 39°F
and 104°F.
The relative air humidity at the installation site must be between 10 and 95% (without
condensation).
6.4 MANUAL TRANSPORT
The pump can be moved manually without lifting equipment.
6.5 ASSEMBLY AND INSTALLATION
Info
Ensure that the national explosion prevention rules and regulations are observed when
setting up the device.
This pump can be used as part of a spraying system or it can be used in a TwinControl
system, for example. A variety of supplemental components for this pump can be found in
the WAGNER liquid coating or accessories catalogues. So that the pump can be separated
from the rest of the system, the correct product valve must be mounted in the product line.
– Further valves (e.g. spray guns) downstream of the product non-return valve are not
discussed in this manual. Observe superordinate operating manual!
