Operating manual Piston Pump EvoMotion 5-125
6 Assembly and Commissioning
28 Order number 2316596 | Edition 03/2021
6.5.2 Air Supply Lines
WARNING
Hose connections!
Risk of injury and damage to the device.
4 Do not mix up hose connections of product hose and air hose.
4 Ensure that only dry, clean atomizing air is used in the spray gun! Dirt and moisture in
the atomizing air worsens the spraying quality and spray pattern.
6.5.3 Product Supply Lines
DANGER
Bursting hose, bursting threaded joints!
Danger to life from injection of product.
4 Ensure that the hose material is chemically resistant to the sprayed products.
4 Ensure that the spray gun, fittings and product hose between the device and the
spray gun are suitable for the pressure generated in the device.
4 Ensure that the following information can be seen on the high-pressure hose:
4 Manufacturer
4 Permissible operating pressure
4 Date of manufacture.
6.6 GROUNDING
WARNING
Discharge of electrostatically charged components in atmospheres containing
solvents!
Explosion hazard from electrostatic sparks.
4 Clean the pump only with a damp cloth.
WARNING
Heavy paint mist if grounding is insufficient!
Risk of poisoning.
Insufficient paint application quality
4 Ground all device components.
4 Ground the work pieces to be coated.
