Operating manual Piston Pump EvoMotion 5-125
14 Spare Parts
Order number 2316596 | Edition 03/2021 55
14.4 AIR MOTOR M80 EM C60
B_03469
1
28
29
2
3
4
5
7
8
9
13
31
32
33
34
35
14
6
23
25
19
26
16
24
11
7
10
3
17
15
22
21
20
12
30 Nm; 22.1 lbft
35 Nm; 25.8 lbft
20 Nm; 14.7 lbft
4.5 Nm; 3.3 lbft
29
29
27
27
30
29
29
30
18
Installation instructions
Always mount piston rod (12) from the bottom to the top, through the rod seal which is
present (18).
Pos K Stk Order no. Designation
1 1 U3B08018060A Air motor M80 EM C60
2 1 F132.91C Motor flange, upper, M80 EM
3 ♦⋆ 2 L108.06 O-ring
