WAGNER EvoMotion 5-125 User Manual

Operating manual Piston Pump EvoMotion 5-125
5 Description
20 Order number 2316596 | Edition 03/2021
Stk Order no. Designation
1 9992504 Separating agent 250 ml
1 2316595 Operating manual, in German
1 See Chapter EU Declaration of Con-
formity [861]
Declaration of Conformity
1 See Chapter Languages [86] Operating manual in the local lan-
guage
The delivery note shows the exact scope of delivery. Accessories: see Chapter Accessories
[850].
5.5 DATA
5.5.1 Materials of Paint-wetted Parts
Paint-wetted part Product
Pump housing Carbon steel
Piston Carbon steel with silicon carbide coating
Valve balls Stainless steel
Valve seats Stainless steel
Static seals EPDM
Packings PE / T
PE = Polyethylene UHMW
T = Polytetrafluorethylene (PTFE)
Positions of the individual parts: See Chapter Spare Parts [852].
5.5.2 Recommended Packings
WAGNER packings for this device:
Code Product Color
PE Ultra high molecular weight
polyethylene
transparent
T PTFE white
Each product has the following properties, which influence the packings:
Designation PE T
Mechanical stability good poor
Friction coefficient good very good
Sealing force good good
Chemical resistance very good very good
Temperature resistance very good poor
