Operating manual Piston Pump EvoMotion 5-125
5 Description
Order number 2316596 | Edition 03/2021 21
5.5.3 Technical data
Description Units Evo Motion 5-125
Pump ratio 5:1
Flow volume per double stroke (DS) cm³ / cc 125
Maximum operating pressure MPa
bar
psi
4.0
40
581
Maximum possible strokes in operation DS/min 60
Minimum/maximum air inlet pressure MPa
bar
psi
0.2–0.8
2–8
28–116
Compressed air quality: free from oil and wa-
ter
Quality standard 7.5.4 according to ISO 8573.1, 2010
7: Particle concentration 5–10mg/m³
5: Humidity: pressure dew point ≤ 7 °C
4: Oil content ≤5mg/m³
Air inlet diameter (internal thread) mm; inch 8.0; 0.31
Minimum diameter of the compressed air
supply line
mm; inch 9.0; 0.35
Air consumption at 0.6 MPa; 6 bar; 87 psi per
double stroke
nl; scf 4.0; 0.14
Air motor piston diameter mm; inch 80; 3.15
Sound pressure level at maximum permissible
air pressure*
dB(A) 72
Sound pressure level at 0.6 MPa; 6 bar; 87 psi
air pressure*
dB(A) 69
Sound pressure level at 0.4 MPa; 4 bar; 58 psi
air pressure*
dB(A) 62
Product inlet (inside thread) mm --
Product output (inside thread) inch G 1/2"
Weight kg; lb 25; 55
Product pH value pH 3.5–9
Maximum product pressure at pump inlet MPa
bar
psi
--
--
--
Product temperature °C
°F
5–80
41–176
Ambient temperature °C
°F
5–60
41–140
Allowable inclination for operation ∠° ± 10
* Measured A-rated emission sound pressure level at distance of 1m, LpA1m in accordance
with DINEN14462: 2015. Reference measurements have been made by Suva (Swiss National
Accident Insurance Fund).
