ProSpray3.29•3.31 19
GB
Appendix
 
 
To achieve faultless and rational working, the selection of the tip is of the greatest importance.
In many cases the correct tip can only be determined by means of a spraying test.

The spray jet must be even.
If streaks appear in the spray jet the spraying pressure is either too low or the viscosity of the coating material to high.
Remedy:Increasepressureordilutecoatingmaterial.Eachpumpconveysacertainquantityinproportiontothesizeofthetip:
The following principle is valid: large tip = low pressure
small tip = high pressure
There is a large range of tips with various spraying angles.
 
Standard tips
Ifadifferenttiptypehasbeentted,thencleanitaccordingtomanufacturer’sinstructions.
The tip has a bore processed with the greatest precision. Careful handling is necessary to achieve long durability. Do not forget the fact
thatthehard-metalinsertisbrittle!Neverthrowthetiporhandlewithsharpmetalobjects.

1. Turn the relief valve handle fully counterclockwise (k Circulation).
2. Switch off the gasoline engine.
3. Dismount the tip from the spray gun.
4. Place tip in an appropriate cleaning agent until all coating material residue is dissolved.
5. If there is pressure air, blow out tip.
6. Remove any residue by means of a sharp wooden rod (toothpick).
7. Check the tip with the help of a magnifying glass and, if necessary, repeat points 4 to 6.
 

up to 250 bar (25 MPa
 





adjusting tip
Order No.
15
20
28
41
49
0.13 - 0.46
0.18 - 0.48
0.28 - 0.66
0.43 - 0.88
0.53 - 1.37
5 - 35 cm
5 - 50 cm
8 - 55 cm
10 - 60 cm
10 - 40 cm
Paints
Paints,llers
Paints, dispersions
Rust protection
paints - dispersions
Large-area coats
0999 057
0999 053

0999 055


fortheatjetadjustmenttip
OrderNo.



(without tip)

Length 100 cm Order no. 
Length 200 cm Order no. 
Length 300 cm Order no. 
15 cm, F-thread, Order no.  15 cm, G-thread, Order no. 
30 cm, F-thread, Order no.  30 cm, G-thread, Order no. 
45 cm, F-thread, Order no.  45 cm, G-thread, Order no. 
60 cm, F-thread, Order no.  60 cm, G-thread, Order no. 
