WAGO 852 Series User Manual

WAGO ETHERNET Accessories 852 Appendix 29
852-111 Industrial ECO Switch
Manual
Version 1.3.1
8 Appendix
8.1 RJ-45 Cable
Always use category 5e cables to connect your network devices. The pin
assignment is given below:
Table 13: RJ-45 Cable
Contact
Description
Pair
Color
(acc.
EIA/TIA 568B)
4-wire
8-wire
1
TD
D1+
2
White/Orange
2
TD-
D1-
2
Orange
3
RX+
D2+
3
White/Green
4
Not assigned
D3+
1
Blue
5
Not assigned
D3-
1
White/Blue
6
RX-
D2-
3
Green
7
Not assigned
D4+
4
White/Brown
8
Not assigned
D4-
4
Brown
Functions on the RJ45 connector
The industrial ECO switch offers the functions autocrossing und autonegotiation
to the RJ-45 connection.

WAGO 852 Series Specifications

General

Model	852 Series
Category	Switch
Ports	8, 16
Data Rate	10/100 Mbps
Power Supply	24 VDC (typically)
Mounting Type	DIN rail
Switch Type	Managed
