WAGO ETHERNET Accessories 852 Appendix 31
852-111 Industrial ECO Switch
Manual
Version 1.3.1
8.2 Drilling Template for Screw Mounting
The industrial ECO switch can be mounted vertically or horizontally using the
boreholes on the side of the device.
Use the drilling template shown below to mark the boreholes.
Figure 8: Drilling template
