• When using a side discharge mower deck, the
side discharge deector shield must not be re-
moved and must be kept in the lowest possible po-
sition to deect grass clippings and thrown objects
down ward. Orient the side discharge away from side-
walks or streets to minimize cleanup of clippings.
When mowing close to obstacles, orient the side dis-
charge away from obstacles to reduce the chance of
damage to property by thrown objects.
Discharge
Shield
Side Discharge Deector Shield in
Lowest Position
• When operating on a slope, reduce speed and
use caution to start, stop, and maneuver. Avoid
sharp turns or sudden changes in direction. The
maximum recommended slope operating angle
is 15 degrees or 26% grade.
8600-9
60 lb·ft ( 81 N·m )
8600-14
16 in.
15°
52 in.
Maximum Recommended
Slope - Do Not Operate
on Steep Slopes
Maximum Recommended Slope
DANGER
Do not mow or dump grass within 5 feet
(1.5 meters) of an embankment or retaining
wall with drop off.
No Driving Zone
5 FT
MINIMUM
