Controls
BXTR6438
Trailer Wood Chipper
24
4.4.2 Forward – Feed material into Rollers
• Pull the feed roller control bar backward to the third detent
position to start the forward feed. This is the normal
operating position. The control bar stays in this position
until moved.
01564
Fig. 13 – Forward Feed
4.4.3 Reverse Feed Rollers
• Place the feed roller control bar in the second detent
position to reverse the feed rollers.
01565
Fig. 14 – Reverse Feed Rollers
NOTE:
The feed roller control bar can move freely
between Forward and Reverse.
