Wallgate Thrii®
PRODUCT MANUAL Issue 5_3
ORIGINAL INSTRUCTIONS
© 2013 Wallgate Ltd.
Refer to table below
Rear View Side View
Fig.5 Fascia Dimensions (in millimetres)
Model
Fascia height dimension
Thrii_SS
870mm
Thrii_DIS
793mm
Thrii_ST
870mm
