Wallgate Thrii®
PRODUCT MANUAL Issue 5_3
ORIGINAL INSTRUCTIONS
© 2013 Wallgate Ltd.
Fig.6 Typical site installation of Wallgate Thrii unit showing clamping bracket (view on rear)
2 – 3 mm
The switched
fused spur MUST
be accessible from either
the front of the Thrii or
from the rear without
having to open the fascia
