WAM TE - Page 92

TP
1
CON.109.--.T.4L-NL
05.16
-
-
-
-
Code
ØC
UNI
6397
D
DIN
5482
EA EB E1 E2 E3 E4 F1 F2 F3
G3
GxHxL
DIN6885
kg
XSP025..1
25 28 x 25 203 245 42 114 24 65 92 117 11 M10 8x7x36 5
XSP035..1
35 40 x 36 252.5 310.5 58 124 43.5 85 105 137 13 M10 10x8x50 6.5
XSP045..1
45 48 x 44 271.5 353.5 82 143 43.5 85 130 162 13 M12 14x9x70 14
XSP055..1
55 60 x 55 304.5 386.5 82 151 43.5 110 149 210 18 M12 16x10x70 22
XSP065..1
65 75 x 69 337.5 442.5 105 162 45.5 130 171 240 18 M16 18x11x90 32
XSP080..1
80 90 x 84 410 540 130 180 60 170 198 250 22 M20 22x14x110 55
ENDBEARINGASSEMBLY
ENDLAGEREINHEIT
SUPPORTPALIERD’EXTREMITE
EINDLAGERMONTAGE
XSP
Code
Bearing
Wälzlager
Roulement
Lager
Bearings
Wälzlager
Roulements
Lagers
Bearing
Wälzlager
Roulement
Lager
Grease
Fett
Graisse
Smeermiddel
Seal
Wellendichtung
Etanchéité
Afdichting
XSP025 . .1
6206 6206 - 51106 22206CC 0.04 XUC 035
XSP035 . .1
6208 6208 - 51108 22208CC 0.06 XUC 045
XSP045 . .1
6210 6210 - 51110 22210CC 0.1 XUC 055
XSP055 . .1
6212 6212 - 51112 22212CC 0.14 XUC 070
XSP065 . .1
6214 6214 - 51114 22214CC 0.2 XUC 080
XSP080 . .1
6218 6218 - 51118 22218CC 0.4 XUC 100
......E..
......B........A..
↓
↓ ↓
Z
V
↓
↓
34
